19" 33kW ORv3 Power Shelf
CPR-3331 Series

首頁產品 CPR-3331 Series

CPR-3331 Series

For Both NVIDIA & OCP Racks

    KEY FEATURES

  • Peak Efficiency: 96.5%
  • Power Module:
    - 5.5kW x 6 PSU (Minimum redundancy: N+1)
    - Max output: 33kW (6+0) / 27.5kW (5+1)
    - EDPP: Up to 180%
  • Peak Load Capability:
    ≤180% of rated power, ≤0.5ms
    ≤150% of rated power, ≤50ms
    100% of rated power, continuous
  • Multiple Shelf Support (Shelf to Shelf):
    - Power Shelf ↔ Power Shelf (Up to 8 shelves)
    - Power Shelf ↔ BBU Shelf
  • One PMC with integrated BMC (ASPEED 2620) provides communication and connectivity for the power shelf, BBU shelf, power supplies, and BBU modules.
  • Highly accurate droop + active current sharing
  • Direct connection to tap-box / facility – no intermediate PDU
Datasheet
Download
Browse
BASIC SPECIFICATIONS
1RU Height, 19" Width
6 x 5.5kW PSU
1 x PMC with RJ45 Port
2 x Rear RJ45 Port
1 x AC Input
Dimensions 840 x 448 x 43.6 mm (D x W x H)
Warranty 3 Years
INPUT
Voltage AC input: 200 - 277V L-N / 346 - 480V L-L(3W+N+PE)
Frequency 50 - 60Hz
OUTPUT
Parameter 50Vdc / 660A
Max Power 33kW
Ripple & Noise 500mVp-p
ENVIRONMENTAL
Temperature Operating : -5°C to 45°C
Non-operating : -40 to 70°C
Altitude Operating: 0 to 3,050 meters (10,000 feet)
Non-operating: 0 to 10000 meters
Relative Humidity Operating & Storage: 10% - 90% RH, non-condensing
